GE IC698CHS009 Rx7i PACsystem I/O SLOT RACK

GE IC698CHS009 is an IC driven by PACSystem RX7i processor module, which belongs to GE (General Electric) industrial automation products. This product is mainly used as an I/O rack module with 9 slots, of which slots numbered 1 to 8 are 20 mm wide and only support single-slot modules; slot 9 is 40.6 mm wide and supports double-width modules.

Category:
G GE
Share

Related products




Product Introduction

The GE IC698CHS009 is an expansion module designed for use with GE Fanuc's Programmable Logic Controllers (PLCs).

It expands the I/O capabilities of a PLC system by adding additional channels for connecting external devices. This module is essential for expanding control systems to meet more complex automation needs.

The IC698CHS009 rack has a maximum current rating of 20 amps at 5 VDC and 1 amp at -12 VDC, and a maximum current rating of 60 amps at 5 VDC and 4 amps at -12 VDC when using a 350-watt power supply.

The rack has a power supply installed in slot 0 and a CPU in slot 1. The remaining slots can be used for one of the following I/O combinations:

Seven single-width modules (no double-width modules installed)

Four double-width modules

A combination of double-width and single-width modules

Here are some details about the GE IC698CHS009:

Manufacturer: GE Fanuc

Product Number: IC698CHS009

Product Type: Rx7i PACsystem I/O Rack

Description: I/O Rack

Application: Rx7i System

Operating Voltage: 5 to 12 V DC

Power Supply: 100/350 W Power Supply

Rated Current: 20 A (100 W Power)/60 A (350 W Power)

Mounting Type: Rear Mount

Nine-Slot Capacity: Accommodates up to nine I/O modules, providing flexibility in system configuration.

Modular Design: Easily expands and customizes the I/O system.

Daisy-Chain Configuration: Simplifies system wiring and setup.
Power distribution: Provides power to connected I/O modules.
Rugged construction: Withstands harsh industrial environments.
Slot and module support: Supports installation of the Rx7i CPU, I/O modules, and power modules. Slot sensing, software configuration, no DIP switches or jumpers required for I/O addressing.
Electrical characteristics: Operating voltage is typically 24V DC. Communication interface is RS-485, with a communication rate of 9600bps (communication rate in a specific environment, may vary depending on configuration).
Dimensions: Approximately 120mm × 80mm × 40mm (specific dimensions may vary slightly by manufacturer and version).
Weight: Approximately 0.5kg (specific weight may vary depending on material and manufacturing process).
Operating temperature range: 0°C to 55°C (some sources indicate 0°C to 60°C, but a more conservative range is used here).
Material: Aluminum alloy housing, providing excellent heat dissipation and protection.
Compatibility: Seamless integration with GE PACSystem Rx7i series PLCs and other compatible modules ensures system stability and reliability.
In addition, the GE IC698CHS009 has the following advantages4:

Scalability: The module has scalable processing capabilities, and users can create an ideal system today and create a more powerful system tomorrow without changing the software.

Built-in Ethernet communication: The module has built-in Ethernet user support communication, supports SRTP and Modbus TCP/IP application protocols, and provides a real-time link for connected systems.

Support for distributed control and I/O: The module integrates motion control to support a variety of fieldbus interfaces in point-to-point applications, supports distributed control and/or I/O, and users can choose from a variety of fieldbus interface modules that are easy to install and quickly configure.

Support for multiple programming languages: The module can be programmed through Proficy Logic Developer PLC Machine Edition and supports multiple programming languages ​​such as ladder diagram (LDI), instruction list (IL), structured text (ST) and C blocks.

GE IC698CHS009 is widely used in industrial automation, intelligent buildings, power industry and transportation.
