Product Introduction

Technical features
Displacement sensor set: IS200TBCIH1CCD has a set of built-in displacement sensors, which can accurately measure and record the changes of input signals.

Digital output module: The terminal board also has a digital output function, which can convert the digital signal in the control system into a corresponding analog output signal to meet different control requirements.

Group isolation function: IS200TBCIH1CCD has a group isolation function, which can ensure the electrical isolation between different input signals and improve the stability and safety of the system.

High-speed network I/O: Suitable for single, dual and triple redundant systems, providing high-speed and reliable data transmission.

High-performance CPU: Equipped with 50Mb memory, fast scanning time, and can quickly process a large number of input signals.

Main technical parameters

Input voltage, output voltage: both 24VDC.

Working temperature range: -40℃ to +85℃, adapt to various harsh working environments.

Communication protocol: Supports multiple communication protocols to adapt to different control and monitoring needs.

Interface Type: Interfaces with VTCC/VCRC or PDIA I/O packages, depending on the system being used.

Floating Excitation Voltage: Nominal 125VDC, ranges between 100 and 145VDC.

Application Areas

The IS200TBCIH1CCD contact input terminal block is widely used in a variety of complex control systems such as:

Power Generation: Used in power plants equipped with gas turbines to monitor and control analog output signals that are critical to turbine operation and efficiency.

Oil and Gas: Plays a vital role in controlling processes associated with gas turbines used in extraction, refining, and distribution operations.

Chemical Processing: Provides accurate analog output signals for precise control of various chemical processes in the chemical processing industry.

Manufacturing: Ensures smooth operation and control of turbine-driven machinery in manufacturing facilities.

Renewable Energy: Integrates into control systems for renewable energy sources such as wind or solar to effectively manage analog output signals.

Precautions

Compatibility: When purchasing and using, please ensure that the terminal block is compatible with your system, especially with the GE Speedtronic Mark VI series turbine control system.

Installation and Maintenance: Please follow the installation and maintenance guide provided by GE to ensure the correct installation and stable operation of the equipment.

Technical Support: If you have any technical questions or need further assistance, please contact GE's technical support team.

Technical Specifications:

Model: IS200TBCIH1CCD

Brand: GE

Processor Type: Intel Atom E660

Frequency: 1.33GHz

Memory Capacity: 512 MB

Number of Inputs/Outputs: 32

Communication Interfaces: Ethernet, RS-232, RS-485

Operating Temperature Range: -20°C to +60°C

Protection Rating: IP67

Dimensions: 90 x 70 x 25 mm

Weight: Approx. 0.5 kg

About IS200TBCIH1CCD
The IS200TBCIH1CCD is a contact input with group isolation board. It is used in Mark VI Speedtronic systems. The IS200TBCIH1CCD can also be used in MKVIe systems.

The IS200TBCIH1CCD can interface with either VTCC/VCRC or PDIA I/O packages, depending on the system it is used in. The board accepts 24 dry contact inputs. These inputs are connected to the board's terminal blocks. Each terminal block has 12 barrier type terminal blocks. The board has a nominal 125 VDC floating excitation voltage. The range is from 100 to 145 Vdc.

The IS200TBCIH1CCD has three D-type connectors. These connectors can be used to connect cable connectors. These connectors are 37-pin connectors with locking tabs.

The terminal blocks on the IS200TBCIH1CCD typically use #12 AWG wire per connection point. The board's terminal blocks can be unplugged from the board when maintenance is required.
