369-HI-R-0-0-0-0-E GE Multilin 369 Motor Management Relay
The GE Multilin 369 Motor Management Relay is a device designed to monitor and protect three-phase motors in industrial applications. It is highly customizable, allowing the user to adjust it to specific motor parameters and application requirements.
Product Introduction
The 369-HI-R-0-0-0-0-E is a motor protection relay designed to monitor, manage, and protect medium-sized AC motors and their associated equipment. Part of the General Electric Multilin 369 Series, the 369-HI-R-0-0-0-0-E is an adaptive system that "learns" motor needs and provides a series of proactive steps and measures to extend system life and reduce associated costs. The relay's metering capabilities include event reporting, waveform capture, and startup data logging; all of which provide critical insight into system performance and can warn of impending failures. The Multilin 369-HI-R-0-0-0-0-E is approximately 11 cm wide, 30 cm high, and 21 cm long. The 369-HI-R-0-0-0-0-E weighs 10 pounds in the box and 8 pounds outside the box. The unit is housed in a DEMO metal carrying case that is extremely durable, flame-retardant, and corrosion-resistant. Relays should be mounted away from strong magnetic fields and high current conductors or they may become damaged over time.
The front of the relay also includes an RS232 port for connecting to a computer running GE Multilin's industry-leading software, EnerVista 369. Connecting a device like this allows for more rapid modification of set points. Set points are configurable settings that determine the behavior of the relay and can be adjusted to the needs of a specific motor system. Set points are easily configured using Enervista 369's Motor Settings Auto-Configurator, which uses the motor's nameplate and system information to generate the appropriate settings file. The user can then further customize the system by performing manual adjustments in the EnerVista program.
Frequently Asked Questions About the 369-HI-R-0-0-0-0-E
Are there any optional features for the 369-HI-R-0-0-0-0-E?
The Multilin GE 369-HI-R-0-0-0-0-E is equipped with an Enhanced Diagnostics option. This option also provides the device with an Enhanced Faceplate. The Enhanced option also provides the 369 Multilin with a motor health report, motor start data logger, and a more advanced event logger. In addition, the 369-HI-R-0-0-0-0-E includes an additional built-in 12 RTDs compared to the base model.
What are the additional R features of the GE Multilin 369-HI-R-0-0-0-0-E motor management relay, and what types of RTDS come with this option?
The additional 12 RTDs of the R option in the base 369 Multilin motor management relay can be bearing, stator, or environmental. The specific type is software selectable.
What types of motors does the 369-HI-R-0-0-0-0-E protect and monitor?
The GE Multilin 369-HI-R-0-0-0-0-E provides management and protection for three-phase motors. The 369-HI-R-0-0-0-0-E also has the ability to monitor the mechanical systems of these motors in a uniquely customized way for a specific motor using measurements such as cooling rate, motor inrush current, etc.
What optional features are available for the 369 Multilin GE Motor Management Relay?
Some of the optional features that may be included with the base unit Multilin Digital Motor Management Relay include under/over voltage, phase reversal detection, power factor, reverse rotation detection, and underpower. These optional features are all explained in the manual.
What are the phase current input specifications for the 369 Multilin GE Motor Management Relay?
The 369-HI-R-0-0-0-0-E Multilin Motor Management Relay has a 1 A phase current input and a 5 A secondary CT input.
