GE IS220PSVOH1B | 336A5026ADP18 | SERVO I/O | PSVOH1B

The GE IS220PSVOH1B is a servo control module designed for controlling and regulating servo systems in a variety of applications. It is manufactured by GE for its MarkVI or MarkVIe systems, both of which are primarily used to control steam and gas turbine systems. With its compact design and rugged construction, the module is able to withstand harsh operating conditions and is a reliable and efficient solution for servo motor control.

Category:
G GE
Share

Related products




Product Introduction

General Electric GE IS220PSVOH1B | 336A5026ADP18 | SERVO I/O | PSVOH1B. The IS220PSVOH1B is an I/O package that is part of the GE Speedtronic MKVIe gas turbine control. Connect the module power connector located on its side to power it up. The I/O module has a built-in soft start feature that regulates the current level when in use.

The IS220PSVPH1B is a servo control I/O module manufactured and designed by General Electric and is part of the VIe series used in GE distributed control systems. The servo control I/O module is essential for managing and controlling servo motors in applications such as robotics, CNC machines, and automation systems. It acts as an intermediary between the control system (such as a PLC or microcontroller) and the servo motor. The module typically provides a pulse width modulated (PWM) output to provide precise control signals for accurate motor positioning. It also features feedback inputs to receive data from an encoder or resolver, enabling real-time monitoring and adjustment of motor position, speed, and torque. In addition, these modules often include configuration and calibration options to fine-tune performance for specific tasks or machinery. Communication interfaces such as Ethernet, RS-232, or RS-485 ensure seamless integration with a variety of control systems. Overall, servo control I/O modules improve the accuracy, responsiveness, and reliability of automated processes.

Features:
Product Type: Servo Interface I/O Package
Series: Mark VIe
Function: Connects one or two I/O Ethernet networks to TSVO Servo Terminal Boards
Dimensions: 8.83 in. (22.44 cm) x 3.50 in. (8.89 cm) x 3.94 in. (10.00 cm)
Weight: 0.45 kg
I/O Interface: IS220PSVOH1B provides an electrical interface between one or two I/O Ethernet networks and TSVO Servo Terminal Boards1.
Servo Valve Position Loop Processing: Uses WSVO servo drive module to process two servo valve position loops.
Panel Design: The front panel of PSVO has multiple LED indicators to indicate status, including power and Attn LEDs, and two LEDs labeled ENA1/2.
Processor Speed: 600MHz
Supply Current: 60A (rated current 115A)
Supply Voltage: 110-220V
Power: 50W
Compatible Systems: MarkVI or MarkVIe systems, mainly used to control steam and gas turbine systems
LED Indicators: Displays Ethernet (ENet1/ENet2) status, power, and attention (Attn)
Configuration: Configured using the Control System Toolbox application
Pulse Width Modulation (PWM) Output: Generates control signals with different pulse widths to adjust the position, speed, and torque of the servo motor.
Feedback Processing: Receives and processes feedback from encoders or resolvers to monitor the actual position, speed, and torque of the servo motor, ensuring accurate control and adjustment.
Position Control: Precise control of motor positioning allows precise movement and adjustment as needed by the automation system.
Speed ​​Control: Regulates the speed of the servo motor to meet specific requirements and ensure smooth operation.
Torque Control: Adjusts the torque output of the motor to meet load demands and prevent overload or poor performance.
Configuration and Calibration: Allows the user to configure and calibrate module settings to optimize performance for different applications and machinery.
Communication Interface: Facilitates communication with the control system through various protocols such as Ethernet, RS-232 or RS-485, enabling integration and data exchange with wider automation systems.
Error Detection and Diagnostics: Monitors system performance and identifies problems or faults, providing diagnostic information to ensure reliable operation and maintenance.

The GE IS220PSVOH1B is a servo control module designed for controlling and regulating servo systems in a variety of applications. It is manufactured by GE for its MarkVI or MarkVIe systems, both of which are mainly used to control steam and gas turbine systems. With its compact design and rugged construction, the module is able to withstand harsh operating conditions and is a reliable and efficient solution for servo motor control.
