GE IS200WEMAH1ACA Mark VI Turbine control system circuit board (IS210BPPBH2CAA)
GE IS200WEMAH1ACA Mark VI Turbine Control System Board (IS210BPPBH2CAA). The GE IS200WEMAH1ACA is a component of the GE Mark VI Turbine Control System, designed for the Speedtronic MKVI system. This system is used to monitor and control all aspects of the gas turbine, providing a comprehensive set of features to ensure optimal performance and reliability. The IS200WEMAH1ACA and its counterpart, the IS210BPPBH2CAA, play a vital role in the operation of these systems.
Product Introduction
The IS200WEMAH1ACA is concerned with processing and managing signals associated with turbine operation, including but not limited to input/output signals from various sensors and actuators. These signals can include parameters such as temperature, pressure, speed, and position. The board may also handle communication protocols, interface with other components of the control system, and may contribute to the overall decision-making process for controlling turbine operation.
The IS200DAMAG1ACA printed circuit board is a gate drive amplifier and interface board for the Innovation Series 620 frame low voltage drive. The Innovation drive is used as part of the General Electric Mark VI Speedtronic system for controlling gas and steam turbines.
The IS200DAMAG1ACA is used in conjunction with a single IGBT module for the upper phase arm and a single IGBT module for the lower phase arm. These are typically CM1000HA-28H Powerrex IGBTs. The DAMA board is designed to connect directly to the Bridge Personality Interface board and to the gate, emitter, and collector terminals on the IGBT.
The IS200DAMAG1ACA is a small board with only a few components mounted. This includes four LED indicators (DS1 through DS4). These LEDs are either green or yellow and light up in the following pattern: DS1 (yellow) lights up when the upper IGBT is on, while DS3 (green) turns on when the same IGBT is off. DS2 (yellow) and DS4 (green) follow the same pattern on the lower IGBT. The boards also include a 12-pin vertical connector and a 6-pin vertical connector, as well as multiple resistors, capacitors, diodes, and transistors. The board is cut out in several places within the body of the board, bears the GE logo, and is labeled with several codes.
AX Control typically keeps existing stock of this and other GE components as well as replacement parts from Woodward, Reliance, Cognex, and other manufacturers. If you are upgrading your plant, feel free to contact us to sell us your surplus stock. There is a form on our website.
The IS200CABPG1ACA is a GE Control component backplane for the Innovation Series drives.
The IS200CABPG1ACA is also known as the CABP board. The purpose of this board is to connect and interact with external signals for the board that is plugged into it. The board provides connections to other external interfaces. Some of these connections include power input, ISBus ports, diagnostic tools, front panel meters, and front panel keypads. This board is typically mounted in an Innovation Series board rack. This rack is able to provide mounting points for the board that plugs into the IS200CABPG1ACA.
The IS200CABPG1ACA is designed so that all non-board connections cannot be accidentally plugged into the wrong jacks. The board connections on the board tend to use different types of connections, are individually keyed, or have the same pinout so they can be interchanged without causing any damage to the board. Only certain boards can be plugged into the CABP board. The BAIA board is assigned to slot 1. The DSPX board is assigned to slot 2. Slot 3 is occupied by an ACL_ board or GBIA/PBIA module. Slot 4 is assigned to a BIC_ board. Assign a BPI_ or FOSA board to slot 5. The E1 and E2 pin connectors on this board are connected to GND. The E3 and E4 pin connectors go to CCOM. The J1-J12 connectors on this board are the external interface connections. The J13-J21 connectors are the actual card slots.
