Product Introduction

technical parameter
Sensitivity: 17.5mV/mm/s
Working voltage: 220V
Output frequency: 50kHz
Weight: 0.74kg
Working principle : The sensor consists of a seismic block and a measuring coil supported by spring plates, and the measuring element can move in the magnetic field of a circular permanent magnet. When the sensor housing vibrates with the measured object, the seismic block is relatively stationary due to inertia, and the measuring coil cuts the magnetic induction line in the magnetic field, generating a voltage signal proportional to the vibration velocity.

Product Features
Accurate measurement: High sensitivity, capable of accurately measuring vibration velocity, providing precise data for equipment status monitoring.
Strong anti-interference ability: The measurement coil has high output and low impedance, and has strong anti-interference capability.
Wide working temperature range: up to 200 ℃, can adapt to various industrial environments.
Good protection performance: The waterproof protection level is IP55 or IP65, which can effectively prevent dust and water.
Explosion proof performance: Connect the safety barrier (zone 1) with an explosion-proof rating of EEx ib II B/II C.

Application Fields
Rotating machinery monitoring: widely used in various turbomachinery, fans, compressors, gearboxes, water pumps, coal mining machines, etc., it can measure their vibration speed and timely detect abnormalities such as imbalance, misalignment, and bearing failures.
Industrial automation: Monitoring and controlling the operating speed of equipment such as motors and conveyor belts on industrial automation production lines to ensure the stability and reliability of the production process.
Energy field: In energy production sites such as power plants, vibration speed monitoring of generator sets and other equipment is carried out to ensure safe and stable operation of the equipment.
