Product Introduction

technical parameter
Sensitivity: 28.5mV/mm/s (723.9mV/in/s)
Frequency range: 4Hz to 1000Hz
Natural frequency: 4.5Hz ± 0.75Hz at 20 ° C
Lateral sensitivity: 0.27 at 110Hz
Vibration amplitude: Mechanical limit peak to peak value of 3000 µ m (some can reach 4000 µ m), amplitude linearity<2%
Maximum acceleration: continuous peak to peak value of 10g (98.1m/s ²), intermittent peak to peak value of 20g (196.2m/s ²)
Maximum lateral acceleration: 2g (19.62m/s ²)
Damping coefficient: about 0.56 at 20 ° C and about 0.42 at 6100 ° C
Resistance: 1875 Ω± 10%
Inductance: ≤ 90mH
Capacitor:< 1.2nF

Installation parameters
Installation direction: Horizontal installation, allowable deviation of ± 10 °

Environmental parameters
Working temperature range:- 20 ° C to+100 ° C
Protection level: IP55
Relative humidity: 0 to 100%, non condensing

Product Features
Non contact measurement: does not come into contact with the rotating shaft, suitable for applications where the shaft may be contaminated or damaged.
High precision: It can provide accurate speed measurement results with an accuracy of ± 0.1%.
Band width: capable of measuring speeds within the range of 0 to 5000rpm.
Strong anti-interference ability: The measurement coil has high output and low impedance, enabling the sensor to effectively resist interference.
Durable and sturdy: Designed to withstand harsh industrial environments.
Application field: Suitable for measuring the casing vibration of rotating machinery such as steam turbines, gas turbines, water turbines, compressors, pumps, fans, etc. It is a commonly used sensor for MMS6000 and MMS3000 rotating machinery monitoring and protection systems.

Many products are not yet on the shelves please contact us for more products.

If there is inconsistency between the product model and the display picture, the model shall prevail, please contact us for specific product pictures, we will

arrange to take pictures in the warehouse to confirm!
