Product Introduction

Range of ProductModicon Quantum automation platform

Product or Component TypeMultifunction input module

Number of terminals40

ComplementaryFunction of moduleStatus logging counting 500 Hz

Status monitoring on discrete inputs

Time and date stamped event logging

Time synchronisation protocolDCF77

IRIG-B

Product compatibilityUnity Pro V4.1 - without IRIG-B or TXSNTP100 function

Unity Pro V5.0 - without IRIG-B or TXSNTP100 function

Unity Pro V6.0 - without IRIG-B or TXSNTP100 function

Unity Pro V7.0

Group of channels2 groups of 16 inputs process input

Discrete input number1 24 V clock signal input

32 24...125 V process input

Switching voltage125 V 1 mA process input

24 V 6 mA process input

48 V 2.5 mA process input

60 V 2.5 mA process input

Maximum power consumption in W7.5 W process input

InsulationBy optocoupler clock signal input

Insulation between group of channelsBy optocoupler

Anti bounce filteringConfigurable from 0 to 255 ms

Input stateInversion configurable

Acquisition time1 ms clock signal input

Input current5 mA clock signal input

Electrical connectionCable - shielded cable <1968.5 ft (600 m) process input

Cable - unshielded cable <1312.3 ft (400 m) process input

Connections - TerminalsScrew terminal block

Local signallingfor communication on the bus (Active) 1 LED (green)

for self test OK, module ready (R) 1 LED (green)

for fault (F) 1 LED (red)

for status of inputs (1 to 32) 32 LEDs

Current consumption300 mA 5 V DC bus

20 mA 24...125 V DC external power supply per group of channel

Module formatStandard

Net Weight0.99 lb(US) (0.45 kg)

EnvironmentResistance to electrostatic discharge4 kV contact IEC 801-2

8 kV on air IEC 801-2

Resistance to electromagnetic fields9.1 V/m (10 V/m) 80...2000 MHz IEC 801-3

Ambient Air Temperature for Operation32…140 °F (0…60 °C)

Ambient Air Temperature for Storage-40…185 °F (-40…85 °C)

Relative Humidity95 % without condensation

Operating altitude<= 16404.2 ft (5000 m)

Protective treatmentTC

StandardsHazLoc

UL 508

Product CertificationsUL

C-tick

CS
