Product Introduction

About the DS200TCEBG1BAA
This DS200TCEBG1BAA printed circuit board product was originally designed and produced by General Electric for use in its Mark V line of turbine control systems. The Mark V series to which this DS200TCEBG1BAA printed circuit board (PCB for short) belongs is now obsolete, as the manufacturer deemed the product obsolete and therefore discontinued production a few years after its initial release. In fact, the Mark V series of this DS200TCEBG1BAA Mark V series of products still has specific applications in newly developed applications, including management and control systems for wind, steam and gas turbine automated drive components, which you may have already known based on the full extended series name inserted earlier. The Mark V series of this DS200TCEBG1BAA circuit board is broader and can therefore also be defined as an ideal GE product line, as it is one of the latest GE Mark product lines developed to utilize Speedtronic control system technology in a range of products. This DS200TCEBG1BAA PCB was developed for the specific functional role of the protection terminal expansion board, although it is not the original development product for this specific Mark V series function. The original protection terminal expansion board developed for the Mark V series is the DS200TCEBG1 mother printed circuit board, which lacks the three revision history of this DS200TCEBG1BAA PCB.

Main Features
High-performance processor: Adopts high-performance 32-bit RISC processor, with fast response time and powerful processing capabilities, capable of meeting various application requirements.
Expandable I/O interface: Provides expandable digital input/output interface, supports a variety of analog and digital signals, and is convenient for users to add expansion modules according to actual needs.
Multiple communication interfaces: Supports multiple communication interfaces such as RS485, Ethernet, etc., which is convenient for data exchange and integration with other devices and systems.
High reliability and durability: Adopts high-quality materials and components, has good durability and reliability, and is suitable for various harsh industrial environments such as high temperature, high humidity, vibration, etc.
Easy to program and maintain: Supports multiple programming languages ​​such as C and C++, which reduces the difficulty of programming, and provides rich technical documents and tools for easy maintenance and troubleshooting.

Technical specifications
Dimensions: 170 mm x 105 mm x 32 mm
Weight: about 120 grams
Storage temperature: -40°C to +70°C (or -40°C to +85°C)
Ambient humidity: 5% to 95% relative humidity (no condensation)
Protection level: IP20

Application scenarios
GE DS200TCEBG1BAA protective terminal expansion board is widely used in various industrial scenarios that require digital signal processing, including but not limited to:
Power plants: In thermal power generation, hydropower generation, nuclear power generation and other power plants, it is used to expand the digital input/output interface of the control system to monitor and control the status of equipment such as generators, transformers, and switch cabinets.
High-voltage transmission lines and substations: Used to expand the digital interface of the control system to monitor and protect the status of the transmission line.
Industrial Automation: Plays a role in automation control systems in industries such as machinery manufacturing, food processing, packaging, printing, textiles, logistics, etc.
Wind Power Generation and Water Treatment Systems: Used to monitor and control the operating status of wind turbines and the operating parameters of water treatment equipment.

Hardware Tips and Specifications
Like any Mark V series product in our new and expanded refurbished stock here, the specific functional role of this DS200TCEBG1BAA PCB is consistent with the specific series of functional inducing hardware components and component specifications connected to its standard Mark V series components. The GE Protection Terminal Expansion Board DS200TCEBG1BAA has 3 bayonet connectors, 4 signal transformers, and 1 26-pin connector. It also contains 4 10-pin connectors and 3 20-pin connectors. The signal transformer on the circuit board is used to increase the signal compatibility between the two devices. There are also 3 20-pin connectors mounted on the circuit board. The 20-pin connectors are marked as JKZ, JKX, and JKY. The 20-pin connector is connected to the signal transmission ribbon cable. Signals are routed to the DS200TCEBG1BAA circuit board from other circuit boards inside the drive. Other signals are routed to other circuit boards in the drive. Fortunately, for your convenience with the DS200TCEBG1BAA personalized product page here, the various connectors for this DS200TCEBG1BAA PCB are listed in the DS200TCEBG1BAA instruction manual embedded in the Manuals tab above. As mentioned earlier, each connector for this DS200TCEBG1BAA PCB will come with its own factory printed named label. Some of the various connectors that are important to the assembly of this DS200TCEBG1BAA Mark V Series product include:

JKX/Y/Z TCEA Board Various Signal Connectors

JMP TCCB Board PT and CT Signal Connectors

JU PTBA Board Magnetic Pickup and Flame Detect Signal Connectors

JV PTBA Board PT and CT Signal Connectors

JVA PTBA Board Flame Detect Signal Connectors

JWX/Y/Z Board TCEA Board Conditioning Signal Connectors

JPU Connector

JPV Connector

JPW Connector
Each of the above connectors in the normal assembly of this DS200TCEBG1BAA Mark V Series product is named by its respective factory printed naming label, its Mark V Series compatible product, and ultimately the unique connection designed for the signal style transmitted to the DS200TCEBG1BAA board and its larger Mark V Series automatic drive assembly. The DS200TCEBG1BAA functional product number for this DS200TCEBG1BAA PCB can be considered another quality source of DS200TCEBG1BAA board hardware component and component specification information, revealing details including this DS200TCEBG1BAA board's normal Mark V series assembly version, its normal PCB coating style, its first set of Mark V series product groupings, and ultimately its complete triple revision history. Ribbon cables are composed of fragile thin wires, so special care is required when disconnecting or connecting them. When you plan to disconnect a 20-pin ribbon cable, always label the cable first to indicate which connector it is connected to. Doing so will reduce the chance of connecting the ribbon cable to the wrong connector, forcing the installer to reconnect the cable and delaying the drive from getting back online. After the ribbon cable is labeled, hold the ribbon cable connector at the end of the cable and gently pull it out of the connector. If necessary, use your other hand to hold the board and prevent it from moving. Move the ribbon cable aside so that the board can be accessed. However, do not interfere with the cable routing. The ribbon cable routing is designed to reduce the interference that can be caused when the ribbon cable is run in parallel with the power lines.

DS200TCEBG1BAA
The Protection Terminal Expansion Board (TCEB) scales the PT and CT signals used by the TCCB board. These signals are for generator and bus voltages and line currents and are connected to the PTBA terminal board. The emergency overspeed and flame detection signals come from the PTBA terminal board and pass through the TCEB board to the TCEA board for processing. The 335 V DC required for the flame detector equipment passes from the TCEA board through the board, is conditioned, sent to the PTBA terminal board and output to the sensor. The alarm horn for the Mark V LM is also located on the TCEB board

FAQs about the DS200TCEBG1BAA
What signals can the DS200TCEBG1BAA scale?
The DS200TCEBG1BAA scales the PT and CT signals used by the TCCB board in the <R5> core.
Where do the emergency overspeed and flame detection signals on the DS200TCEBG1BAA come from?
The emergency overspeed and flame detection signals come from the PTBA terminal board and are sent to the TCEA board for processing via the DS200TCEBG1BAA.
Where can I find a diagram for the DS200TCEBG1BAA?
You can find a diagram for the DS200TCEBG1BAA in Figure 5-9 of the Mark V LM Turbine Control Manual (Manual GEH-6353). The diagram in the manual shows a typical layout of the TCEB board, which is the DS200TCEBG1BAA.
