GE F650BABF1G0HI | Multilin F650 Digitale Bay Controller

The GE F650BABF1G0HI is a digital bay controller from GE Multilin. It is a multifunctional device used to protect feeders and busbars inside a power distribution system.

Category:
G GE
Share

Related products




Product Introduction

GE F650BABF1G0HI | Multilin F650 Digital Cabinet Controller. The GE F650BABF1G0HI is a model of the GE Multilin F650 Digital Cabinet Controller. It is a digital cabinet controller designed for a variety of different applications, including primary protection of distribution feeders and transmission lines, and backup protection of transformers, busbars, capacitor banks, etc.

The F650 incorporates industry-leading communication technology to provide advanced monitoring and metering capabilities. It also provides high-speed protection and control for feeder management.

GE F650BFDF1G1HI6E | Digital Cabin Controller | Multilin F650. The GE F650BFDF1G1HI6E is the digital cabin controller for the Multilin F650 system. The device is part of the GE Multilin F650 product line, a range of industrial automation products designed for a variety of applications in the energy industry.

The F650 Digital Cabin Controller is a versatile device capable of handling a wide range of tasks. It monitors and controls connected devices in real time, ensuring optimal performance and efficiency. The controller can handle a wide range of inputs and outputs, making it suitable for different applications.

A key feature of the F650 controller is its ability to perform boot code updates. This feature allows for updating firmware and kernel versions, thus enhancing the overall performance and security of the system.

The controller also features a comprehensive user interface with various customization options. It offers the possibility to select an initial logo, a simplified metering screen showing the main values, or both. It also supports snapshot events, control events, oscilloscope, fault logger, data logger, and multi-language visualization of metering.

The F650 controller also comes with a built-in web server, allowing remote access and control. This feature enhances the flexibility and convenience of the system, as users can monitor and manage the system remotely.

Specifications:
Voltage input: 110-250VDC / 120-230VAC
Power consumption: Approx. 30W
B = Basic Display
Rear Serial Communication Board 1: A = Windpower RS485
Rear Wall Communication Board 2: B = 10/100 Base TX
I/O Board in Slot F: 1 = 16 Digital Inputs + 8 Outputs
I/O Board in Slot G: 0 = None
Auxiliary Voltage: HI = 110-250 Vdc (Range 88 – 300). 120-230 Vac (Range 96 – 250)
Language: - = English
Communication Protocols: - = Modbus RTU, TCP/IP, DNP 3.0 Level 2, IEC 60870-5-104
Environmental Protection: - = Environmental Protection (Chemical) Environmental Protection Conformal Coating
Enhanced Display: - = With RS232 Display
Weight: 5 kg

Features:

Comprehensive Protection Suite: It provides various functions to prevent electrical faults, including overcurrent protection.

Enhanced Reliability: Ensures stable operation of power systems by automatically isolating faults.

Automation Potential: It can promote automation changes, with the potential to reduce manual intervention and workload.

Applications:

Distribution Systems: Protect feeders and bus towers from the effects of electrical faults such as overcurrent.
Substation Automation: As part of a larger system, it can promote the automation of various functions within the substation.
