GE 369-HI-R-M-0-0-0-E General Electric Multilin's 369 series
GE 369-HI-R-M-0-0-0-E is a high-quality relay designed for electrical control and switching purposes, belonging to the GE Multilin 369 series. This relay is designed to protect and control motors and their accessory components, with multiple functions such as pre-trip alarm, over-torque correction, etc. Its compact design makes it easy to install and operate, suitable for a wide range of applications in various industries.
Product Introduction
The 369-HI-RM-0-0-0-E is part of the General Electric Multilin 369 series of motor management relays. This model of the 369 and its upgrades and accessories are being discontinued and are in last-time-buy status. Some upgrades, such as conformal coating as a protective layer against corrosion, heat, dust, and moisture, can still be added after the product line is discontinued.
The 369-HI-RM-0-0-0-E is designed to protect and control motors and their accompanying components. The 369 achieves this through a variety of built-in features, some of which include:
Technical Specifications:
Manufacturer: GE Multilin
Product Number: 369-HI-R-0-0-0-0-E
Product Type: 369 Motor Management Relay
369: Base Unit (No RTD)
HI: 50-300 VDC / 60-265 VAC Control Power
R: Optional 12 RTD Inputs (Built-in)
0: No Optional Metering or Backspin Detection
0: No Optional Fiber Optic Ports
0: No Optional Protocol Interfaces
0: No Harsh Environment Options
E: Enhanced Diagnostics via Enhanced Panel
Metering: The 369 can monitor quantities such as voltage, watts, frequency, and energy, and generate protection functions based on the value data generated.
Event Logging: After a trip, the 369 is able to directly report the cause of the trip as well as the temperature and data values at the time of the trip, allowing the user to analyze what went wrong with the system.
Pre-trip alarm: When a trip is caused by ground fault, mechanical jam, RTD overheating, etc., the 369 can notify the user before the trip.
Motor Health Report: The relay can use learned information and system trip history to determine when and where maintenance is needed.
Waveform recording: Three waveform recordings are triggered on trip and capture sixteen cycles of data. Phase current, ground current, and contact input status are captured during this process.
The rich data generated and protection functions employed by the 369-HI-RM-0-0-0-E relay help reduce troubleshooting time and extend system life, making it an excellent choice for medium-sized motors.
The GE 369-HI-RM-0-0-0-E is a motor management relay from the General Electric Multilin 369 series. It is designed to protect and control medium-sized motors and their components. The relay offers a variety of built-in functions including metering, event logging, pre-trip alarm, motor health report, and oscilloscope. Metering: The relay can monitor quantities such as voltage, watts, frequency, and energy and generate protection functions based on the measurements.
Event Logging: The relay can report the cause of a trip as well as the temperature and data values at the time of the trip, helping the user analyze system problems.
Pre-trip Alarm: When a trip is caused by a ground fault, mechanical jam, RTD overheat, etc., the relay can notify the user before the trip.
Motor Health Report: The relay uses learned information and the system trip history to determine when and where maintenance may be needed.
Oscillographic: The relay captures three waveform records triggered when a trip occurs, capturing sixteen cycles of data. This includes phase and ground currents as well as contact input status.
The GE 369-HI-RM-0-0-0-E relay is a motor management relay with a variety of built-in features to protect and control medium-sized motors.
The 369-HI-RM-0-0-HE from General Electric Multilin is a motor protection and management relay designed to protect medium-sized motors and their accompanying components. The motor is able to "learn" and adapt to the needs of each motor, more specifically configuring the system to which it belongs.
The relay can monitor and log total accumulated megawatt hours, motor trip type, total number of motor trips, number of motor starts, and total run hours. In addition to being a useful source of general information, this data can help diagnose motor faults and plan future maintenance.
The HI-RM-0-0-HE provides users with a variety of inputs and outputs to meet their motor management needs. A speed switch input allows the use of an external speed device, which can easily distinguish between normal starts and locked rotor conditions and shut down the relay when conditions are unfavorable. Other inputs include waveform capture and a digital counter.
This particular model includes enhanced diagnostics and panel options as well as conformal coating. The enhanced panel design is cleaner and included with the diagnostics option. Conformal coating is a thin polymer film that protects the relay from varying temperatures, corrosive materials, dust, and humidity.
The HI-RM-0-0-HE weighs approximately 10 pounds and is housed in a DEMO metal carrying case that provides some protection from operating environmental factors. The enclosure is flame retardant and corrosion resistant and should be installed away from strong magnetic fields or high current conductors that may damage the relay over time.
Frequently Asked Questions about 369-HI-RM-0-0-HE
Can you please provide more details on the optional metering package included in the 369-HI-RM-0-0-HE Multilin GE Digital Motor Management Relay for monitoring three-phase motors?
The 369-HI-RM-0-0-HE and other Multilin relays in the 369 Multilin GE Motor Management Digital Relay series may be equipped with an optional metering package if specified by the M option in the third position of the part number. This is referenced in 369-HI-RM-0-0-HE . This additional metering option provides the base unit with power metering parameters such as kW, kvar, kVA, kWh, MWh, kvarh, Mvarh, power factor and frequency parameters with high accuracy and resolution. The event logging capacity of this power metering option is the capacity to log the last 512 events. The triggers for this event are power failure, alarm, self-test, waveform capture and trip events.
What is the analog output of Option M included in the GE Multilin 369-HI-RM-0-0-HE Multilin General Electric Digital Motor Management Relay?
The 369-HI-RM-0-0-HE Multilin General Electric Digital Motor Management Relay has a programmable analog output and comes with the Option M feature. The three possible output ranges are 0-1 mA, 0-20 mA, and 4-20 mA. The maximum loads for each of these three ranges are 2400, 600, and 600 ohms, respectively.
