Product Introduction

1. Basic Information
Model: 6SE7036-1EE85-1HA0
Brand: SIEMENS
Series: SIMOVERT MASTERDRIVES series of high-performance inverters, designed for industrial four-quadrant drive scenarios.
Input voltage: DC 510-620V, suitable for motor power range 0.5kW~315kW.
Installation method: BoardMount, compact size (typical size: 7.50×13.50×6.60cm), suitable for standard industrial cabinets.
2. Core functions and technical features
2.1 Four-quadrant operation and energy management
-- Integrated PER2 module, realizes bidirectional flow of electric energy through precise IGBT control, supports energy feedback to the grid, and improves energy saving efficiency by 40%-60%. -- Active front-end (AFE) technology stabilizes the DC bus voltage (±1.5% fluctuation range) to ensure system stability.

‌2.2 Dynamic response and protection ‌
-- Instantaneous overload capacity: supports ‌250% rated current for 0.5 seconds‌ to meet short-term peak load requirements.

-- Thin film capacitor technology achieves fast charging and discharging (<3ms) to ensure command response speed.

-- Multiple protection mechanisms: overvoltage (DC bus voltage exceeds 1150V to trigger protection), overcurrent, and overheating protection.

‌2.3 Communication and integration ‌
-- Compatible with industrial protocols such as ‌Profibus DP‌ and ‌Profinet‌, and supports seamless networking with Siemens PLC (such as S7-1500 series).

-- Provides a remote monitoring interface to diagnose device status in real time and reduce downtime.

‌2.4 Modularity and Reliability‌

-- Modular design facilitates expansion and maintenance, and supports multi-motor coordinated control (such as rolling mills, conveyor belts, etc.).
‌-- IP66 protection level, suitable for harsh industrial environments such as dust and moisture.

3. Application Fields‌
‌-- Industrial Automation: High dynamic response scenarios such as steel rolling mills, oil pump equipment, and elevators.
‌-- Precision Manufacturing: Thin film copper foil processing, machine tool control, and other scenarios that require high-precision speed regulation.
‌-- Energy-saving scenarios: Variable load equipment such as fans and water pumps, which reduce energy consumption through energy feedback.

4. Technical parameters
Input voltage: DC 510-620V
Output frequency range: up to 50000Hz
Protection level: IP66 (dustproof and waterproof)
Applicable motor power: 0.5kW~315kW
Overload capacity: 250% rated current (0.5 seconds)
Communication interface: Profibus DP, Profinet

5. Precautions for use and maintenance
5.1 Parameter configuration: Set motor parameters (such as rated voltage and frequency) through the Siemens Starter software to ensure that they match the actual load.
5.2 Environmental requirements: Avoid high temperature (＞70℃) and strong vibration environment, and clean heat dissipation components regularly.
Ensure that the power supply wiring is reliable to prevent malfunction caused by poor contact.
5.3 Maintenance suggestions:
Regularly check the status of key components such as film capacitors and IGBTs, and replace wearing parts in time.
Monitor the DC bus voltage to prevent overvoltage from triggering protection shutdown.
With its four-quadrant drive capability, high dynamic response and industrial-grade protection design, this inverter has become a core drive solution in the fields of steel, petroleum, precision manufacturing, etc.
