Product Introduction

1. Basic Information
Model: 6SE7036-0TK84-1BH0
Brand: SIEMENS
Series: SIMOVERT MASTERDRIVES series industrial inverter module, designed for high-performance motor control.
Input Voltage: Supports DC 510-620V1, adapted to the motor drive requirements of industrial automation systems.
Installation Method: BoardMount, compatible with standard industrial cabinet layout.

2. Core Functions and Technical Features
2.1 Control Mode and Performance
-- Supports V/F control (scalar control) and vector control (VC), meeting the needs of multiple scenarios from basic speed regulation to high-precision torque control.
-- Integrated direct torque control (DTC) technology to achieve fast dynamic response (such as cranes, elevators and other application scenarios).
-- The output frequency is up to 50000Hz, suitable for high-speed drive and complex industrial systems.

‌2.2 Modularity and scalability ‌
- Adopts a compact modular design (size: 7.50×13.50×6.60cm), which is easy to transport, install and expand the system.

-- Supports multi-motor coordinated control, suitable for complex equipment such as conveyor belts and extruders that require multi-axis synchronization.

2‌.3 Communication and integration capabilities ‌
- Integrated Profibus DP communication interface, can be seamlessly networked with Siemens PLC (such as S7 series).

-- Compatible with USS protocol, supports simple serial communication and remote monitoring.

‌2.4 Energy saving and protection function ‌
- With energy feedback function, it can feed back braking energy to the power grid to improve energy efficiency. -- Integrates multiple protection mechanisms such as overcurrent, overvoltage, and overheating, and adapts to harsh environments such as dust and moisture through the ‌IP66 protection level‌.

3. ‌Application areas‌
‌-- Industrial automation‌: high-precision speed regulation scenarios such as machine tools, packaging machinery, and textile equipment.
‌-- Heavy-duty drives‌: equipment such as cranes and elevators that require fast response and high reliability.
‌-- Energy-saving scenarios‌: variable load equipment such as fans and water pumps, optimizing energy consumption through speed control‌.

4. Technical parameters
Input voltage: DC 510-620V
Output frequency range: up to 50000Hz
Protection level: IP66 (dustproof and waterproof)
Applicable motor power: flexibly configured according to system requirements
Communication interface: Profibus DP, USS
Working temperature: conventional industrial environment (-10℃~70℃)

5. Precautions for use and maintenance
Parameter configuration: The motor parameters (such as rated voltage and frequency) need to be adjusted through the Siemens Starter software to ensure operational stability.
Installation environment: Avoid high temperature and strong vibration environment, and clean the heat dissipation components regularly to maintain performance.
Ensure that the power supply wiring is reliable to prevent malfunction caused by poor contact.
Maintenance suggestions: Check the module status (such as fans and filters) regularly, and replace wearing parts in time to extend the service life.
Through high-performance control, modular design and industrial-grade protection capabilities, the inverter demonstrates the advantages of high efficiency, reliability and flexibility in complex industrial scenarios.
