Product Introduction

Siemens 6SE7036-5GJ84-1BH0 frequency converter is a member of the Siemens SIMOVERT MASTERDRIVES product series and is a fully digitally controlled AC variable frequency transmission device. The following are some of the main features of this frequency converter:

 High efficiency and energy saving

Siemens 6SE7036-5GJ84-1BH0 inverter can effectively control the motor's speed and output power to achieve load regulation, thereby achieving energy saving effects. Compared with the traditional speed regulation method of resistor or reducer, it can significantly save energy.

Stable and reliable

The inverter has high-performance motor control and protection functions. It can monitor the working status and load conditions of the motor in real time, and automatically adjust the output power to ensure the stability and reliability of the motor operation. It has multiple safety protection functions such as overload protection, overheating protection, short circuit protection, etc., which effectively extends the service life of the equipment.

Versatility

Siemens 6SE7036-5GJ84-1BH0 inverter supports multiple working modes and control methods, and can adapt to different working environments and needs. Parameters can be set and adjusted through programming software to achieve switching and combination of multiple functions to meet the requirements of different application fields.

Easy maintenance

The inverter has a friendly human-machine interface and simple operation mode, and can intuitively display the working status and fault information of the equipment. It also supports remote monitoring and diagnosis functions, and can obtain equipment operating data and fault information in real time through the network to facilitate timely repair and maintenance.

High control accuracy

The 6SE70 frequency converter adopts digital control technology and can realize speed adjustment and position control. Through current and voltage control, the motor can be started smoothly and stopped quickly, improving production efficiency and product quality.

Advanced control technology

The inverter adopts advanced full digital control technology and IGBT voltage source pulse width modulation (PWM) technology to ensure efficient operation and high-precision control of the equipment. It has two main control modes: vector control and motion control. Vector control can provide precise torque control and fast dynamic response, and is suitable for applications that require high accuracy, such as motor positioning and servo control. The encoderless vector control is suitable for simple applications such as fans and water pumps. The motor speed is controlled by adjusting the U/f ratio.

Low harmonic current

In order to achieve low harmonic current (incoming line harmonics) for a frequency converter using a conventional DC link, a line reactor with uK=6% needs to be used. This reduces current consumption by approximately 22%, which is equivalent to reducing losses in the power system by approximately 40%. In addition, through reactive power compensation, the power factor cosφ is improved and the power consumption of the entire system is reduced.

Starting reactor: Suitable for the starting stage of the motor, it helps to smooth the current transition and reduce the impact current when the motor starts.

Incoming line reactor: Installed between the inverter and the power grid, it is used to filter out harmonics in the power grid and protect the inverter and other electrical equipment from harmonics.

System rated voltage: 1KV

Rated current: 1A

Insulation structure: dry type reactor

Product features:

Core material: Made of high-quality low-loss imported cold-rolled silicon steel sheets to ensure high magnetic permeability and low loss.

Air gap isolation: Use epoxy laminated glass cloth board as air gap partition to prevent air gap changes during operation.

Coil material: H-grade enameled flat copper wire winding, tightly and evenly arranged, with good heat dissipation performance and beautiful appearance.

Fasteners material: The fasteners of the core column part are made of non-magnetic material to reduce eddy current heating.

Anti-corrosion treatment: All exposed parts are treated with anti-corrosion to extend service life.

Terminal material: The lead-out terminal uses tinned copper tube terminals to improve conductivity.

Performance advantages

Small size: Compared with similar domestic products, this reactor has a smaller size.

Light weight: The lightweight design is easy to install and maintain.

Beautiful appearance: The modern appearance design enhances the visual beauty of the overall equipment.

In the field of industrial automation, 6SE7036-5GJ84-1BH0 is mainly used to control the speed of the motor, adjust the speed and torque in the production process, and achieve efficient production processes. By using this reactor, the harmonics in the power grid can be effectively reduced, the efficiency of electric energy use can be improved, and energy consumption can be reduced. Its design can effectively protect the inverter and other electrical equipment from the influence of power grid harmonics and extend the service life of the equipment.
