Product Introduction

1. Basic Information
Model: 6SE7036-5GK84-1JC0
Brand: SIEMENS
Series: It belongs to the SIMOVERT MASTERDRIVES series inverter control components, which is similar in design to the same series models (such as 6SE7036-5GK84-1JC2) and is suitable for industrial automation scenarios.
Input Voltage: Supports DC 510-620V, suitable for small and medium power motor drive requirements.
Installation Method: Onboard installation, modular structure is compact and easy to integrate into standard industrial cabinets.
2. Core Functions and Technical Features
2.1 Modularity and Compatibility
-- It adopts modular design, supports flexible combination with other Siemens drive components (such as rectifiers and communication modules), and has strong scalability. -- Compatible with DRIVE-CLiQ communication technology to achieve high-speed data interaction and system integration.

2.2 Control performance and protection
-- Support V/F control (scalar control), suitable for basic speed regulation scenarios such as fans and pumps.
-- Integrated overcurrent protection, overvoltage protection and overheating protection to ensure stable operation of the equipment.
-- Instantaneous overload capacity can reach 250% rated current (0.5 seconds) to cope with short-term load fluctuations.

2.3 Communication and industrial applicability
-- Support Profibus DP communication protocol, seamless networking with Siemens PLC (such as S7 series), remote monitoring and parameter debugging.
-- Protection level IP66, suitable for harsh industrial environments such as dust and moisture.

3. Application fields
Industrial automation: Machine tools, conveyor belts, packaging machinery and other scenes that require speed control.
Energy-saving equipment: Variable load equipment such as fans and water pumps, optimizing energy consumption through speed regulation.
Low-voltage system: Adapt to motor drive requirements with rated voltage of 220-620V, such as small production lines or power distribution systems.
4. Technical parameters
Input voltage: DC 510-620V
Output frequency range: Up to 50000Hz (depending on configuration)
Protection level: IP66
Communication interface: Profibus DP, DRIVE-CLiQ
Overload capacity: 250% rated current (for 0.5 seconds)
5. Precautions for use and maintenance
5.1 Parameter configuration: Set motor parameters (such as rated voltage and frequency) through the Siemens Starter software to ensure that they match the actual load.

‌5.2 Installation environment‌:
Avoid high temperature (＞70℃) and strong vibration environment, and clean the heat dissipation components regularly‌.
Ensure that the power supply wiring is reliable to prevent malfunction caused by poor contact‌.

5‌.3 Maintenance suggestions‌:
Regularly check key components (such as cooling fans, capacitors), and replace wearing parts in time‌.
Monitor the status of the communication interface to prevent abnormal control due to signal interference‌.
This model has modular design, high compatibility and industrial-grade protection as its core advantages, and is suitable for motor control needs in general industrial scenarios‌.
