Product Introduction

Technical parameter
Range: ± 1.5mm
Sensitivity: 5.33V/mm
Rated air gap: 2mm
Tested material: electrical conductor, such as steel shaft, etc
Height of the measuring disc on the axis: 40mm
Diameter requirement for shaft: 80mm
Surface linear velocity of the shaft: 0-2500m/s
Working temperature range:- 35℃-+180℃
Temperature tolerance:- 35℃-+180℃
Instantaneous maximum temperature: up to 200 ℃
Threaded/mounting flange: M10 × 1 or 3/8 "-24 UNF-2A
Shell/flange material: stainless steel
The maximum temperature that the cable can withstand:+ 200℃
Pressure resistance: 2 bar
Vibration and impact resistance (25 ℃): 5g at 60Hz

Product Features
Non contact measurement: using the principle of eddy current induction, it does not require direct contact with the measured object, avoiding wear and interference on the surface of the measured object, and is suitable for measuring high-precision and high-speed moving objects.
High precision and high reliability: Advanced design and manufacturing processes ensure high precision and stability of measurements, enabling reliable operation in complex industrial environments and providing accurate data support for the safe operation of equipment.
Multiple installation methods: Provides multiple thread sizes and installation methods, making it convenient for users to install and use according to their actual needs, and can adapt to different equipment structures and installation space requirements.

Application Area 2
In the power industry, it is used to measure parameters such as shaft vibration, displacement, and eccentricity in rotating equipment such as steam turbines and generators, monitor the operating status of the equipment, detect potential faults in a timely manner, and ensure the safe and stable operation of power equipment.
Petrochemical industry: applied to equipment such as compressors and pumps to monitor the movement status of shafts, ensuring the normal operation of equipment in harsh chemical environments and preventing production accidents caused by shaft failures.
Mechanical manufacturing industry: In the production and testing process of various machine tools, gearboxes and other equipment, it can be used to measure the accuracy, vibration and other parameters of the shaft, providing important basis for product quality control and equipment debugging.
