Product Introduction

Range of ProductModicon Quantum automation platform

Product or Component TypePower supply module

Power supply typeSummable

ComplementaryInput voltage48...60 V 48...60 V) DC

Input current3800 mA

Inrush current14 A 40 V

Maximum input power interruption13 ms 48 V

Associated fuse rating2 A, time-lag

Output voltage5.1 V DC

Power supply output current8 A summable

Output overvoltage protectionInternal

Output overload protectionInternal

Power dissipation15.6 W

Alarm output1 NC 6 A 220 V power supply fault

Local signallingfor power (PWR OK) 1 LED (green)

MarkingCE

Module formatStandard

Net Weight1.43 lb(US) (0.65 kg)

EnvironmentStandardsUL 508

CSA C22.2 No 142

Product CertificationscUL

Resistance to electrostatic discharge4 kV contact IEC 801-2

8 kV on air IEC 801-2

Resistance to electromagnetic fields9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3

Ambient Air Temperature for Operation32…140 °F (0…60 °C)

Ambient Air Temperature for Storage-40…185 °F (-40…85 °C)

Relative Humidity95 % without condensation

Operating altitude<= 16404.2 ft (5000 m)
