TRICONEX 3805H ANALOG OUTPUT MODULE

TRICONEX  ANALOG OUTPUT MODULE



Origin: United States



Brand: TRICONEX





Category:
Share

Related products




Product Introduction

Specifications
Output type: Analog
Output current range: 4-20mA output (+6% over range)
Output circuit power requirement: greater than 20Vdc (minimum 1A) under 250 Ω load; When the load is 500 Ω, it is greater than 25Vdc (1A minimum); When the load is 750 Ω, it is greater than 30Vdc (1A minimum); Greater than 35Vdc at 1000 Ω load (1A minimum)
External circuit power supply: maximum+42.5VDC (reverse voltage protection), nominal+24Vdc
Over range protection:+ 42.5VDC, continuous
Switching time: less than 10ms in case of branch failure, typical


performance parameter
Number of channels: 8 outputs
Isolation situation: No isolation point, public return, DC coupling
Resolution: 12 bits
Output accuracy:<0.25% FSR (0-21.2mA) within the range of 4-20mA, temperature range of 32 ° F-140 ° F (0 ° C-60 ° C)
Diagnostic indication: The module status includes pass, fault, activation (one for each module), as well as load, PWR1, PWR2, etc. The color code is pea green
physical characteristics
Size: 135mm × 116mm × 35mm
Weight: 0.45kg


main features
High precision output: With high output accuracy and error control within ± 0.25%, it can provide accurate analog output signals for industrial control processes, ensuring the accuracy of control.
Multi channel design: With 8 analog output channels, it can simultaneously control the analog output of multiple control objects, improving the system's control capability and efficiency. It is suitable for complex industrial scenarios that require multiple analog control.
Wide working temperature range: The working temperature range is from -20 ° C to+70 ° C, which can adapt to various harsh industrial environments. Whether it is a high-temperature furnace workshop or a low-temperature freezer warehouse, it can work stably.
Easy to install and configure: The design is compact, the installation method is simple, and the configuration process is relatively convenient. Parameter settings and functional configurations can be carried out through relevant programming software or control systems, reducing the difficulty and cost of installation and debugging.
Supports multiple communication protocols: Supports Ethernet, Modbus, Profibus and other communication protocols, making it easy to communicate and integrate with other devices and systems, achieving a wider range of industrial automation control and data exchange.
Application areas: Safety Instrumented Systems (SIS) and Distributed Control Systems (DCS) suitable for industries such as petroleum, chemical, power, metallurgy, papermaking, and textiles. They can be used to control regulating valves, frequency converters, and other equipment to achieve precise control of process parameters such as flow rate, pressure, and temperature.
