GE IS215UCVEH2AB Speedtronic MarkVI RTD CARD
GE IS215UCVEH2AB is a double-sided controller designed for GE Speedtronic MarkVI control systems. This controller not only has powerful data processing capabilities, but also supports multiple communication protocols to ensure seamless connection and data exchange with different devices and systems.
Product Introduction
The GE IS215UCVEH2AB is a single board computer designed for the GE Speedtronic MarkVI system, primarily for operating turbine application code. This single board computer is a compact and versatile computing solution for demanding application environments. Here is a detailed introduction to the product:
Design & Specifications
Dimensions & Mounting: The IS215UCVEH2AB is marked as a standard MarkVI controller and is designed as a 6U high, single/dual slot single board computer. It is typically used to operate turbine application code and is located in a VME rack with twenty-one or thirteen slots4.
Operating System: The typical operating system used for this board is QNX. The QNX system is a multi-tasking, real-time operating system designed for high reliability and high-speed industrial applications.
Memory & Performance
Memory Type: The IS215UCVEH2AB has two different memory types, 32 megabytes of DRAM or 16 megabytes of flash memory. This design provides flexible storage options to suit different application requirements.
Processor and Cache: The board uses an Intel Celeron microprocessor running at 300MHz and is equipped with 32MB of DRAM memory. In addition, the system includes a 128KB L2 cache to improve data access speed.
Interface and Communication
Ethernet Interface: The main Ethernet interface (Ethernet1) has twisted pair 10BaseT/100BaseTX technology and RJ-45 connector, supports TCP/IP and EGD protocols, and is mainly used for communication between the controller and the toolbox.
Serial Port: The controller is equipped with two serial RS-232C ports and one Ethernet port. COM1 is dedicated to diagnostic purposes and maintains a baud rate of 9600, while COM2 is dedicated to serial Modbus communication.
Product Features
1. Design and Specifications The IS215UCVEH2AB is marked as a standard MarkVI controller and is designed as a 6U high, single/dual slot single board computer. It is typically used to operate turbine application code and is located in a VME rack with twenty-one or thirteen slots. When located in the control module, it will communicate with other turbine I/O boards via the VME bus.
2. Operating System The typical operating system used by this board is QNX. The QNX system is a multi-tasking, real-time operating system designed for high reliability and high-speed industrial applications.
3. Storage and Performance The IS215UCVEH2AB has two different memory types, 32 megabytes of DRAM or 16 megabytes of flash memory. This design provides flexible storage options to suit different application requirements.
4. Communication and Interface The controller is equipped with two serial RS-232C ports and one Ethernet port. The main Ethernet interface (Ethernet1) adopts twisted pair 10BaseT/100BaseTX technology and RJ-45 connector, supports TCP/IP and EGD protocols, and ensures seamless data exchange and efficient and reliable data transmission within the system.
Application Fields
The IS215UCVEH2AB GE single board computer is suitable for industrial automation, transportation, energy and other fields. Its design makes it an ideal choice for operating turbine application codes and can run stably in harsh industrial environments.
