Bently Nevada 330900-70-00 - PROXIMITY SENSOR PROBE
BENTLYPROXIMITY SENSOR PROBE
Origin: United States
Brand: Bently Nevada
330900-70-00 is a Proximity Sensor Probe developed by Bently Nevada. It is a part of the Bently Nevada 3300 series.
Category:
Share
Related products
Product Introduction
Probe diameter and material: BENTLY330900-70-00 The probe diameter is 8mm, and the coil is encapsulated at the end of the injection molded PPS plastic probe, with a sturdy structure that can resist mechanical damage.
Application scope: This probe is suitable for various mechanical monitoring applications, including radial vibration, axial position measurement, tachometer, and zero speed measurement.
Temperature range: The probe can operate normally within a temperature range of -51 ° C to+177 ° C (-60 ° F to+351 ° F) and is suitable for various environmental conditions.
technical parameter
Linear range: 80 mil (2 mm) high, output value of 200 mV/mil 4.
Frequency response: In the range of 0 to 10 kHz, the frequency response is+0 to -3 decibels, suitable for various mechanical monitoring applications.
Environmental temperature: 0 ° C to 45 ° C (III), incremental scaling factor (ISF) of 7.87 V
(200 mV/mil), gain error of ± 12.5% 2.
Installation and maintenance
Installation method: The preamplifier should be installed floating and electrically insulated from the unit. It is recommended to use a preamplifier protection box for protection.
Cable type: Use three core shielded cables, with a length of up to tens of meters, and the shielding layer should be connected to the instrument ground at a single end in the control room
Probe diameter and material: BENTLY330900-70-00 The probe diameter is 8mm, and the coil is encapsulated at the end of the injection molded PPS plastic probe, with a sturdy structure that can resist mechanical damage.
Application scope: This probe is suitable for various mechanical monitoring applications, including radial vibration, axial position measurement, tachometer, and zero speed measurement.
Temperature range: The probe can operate normally within a temperature range of -51 ° C to+177 ° C (-60 ° F to+351 ° F) and is suitable for various environmental conditions.
technical parameter
Linear range: 80 mil (2 mm) high, output value of 200 mV/mil 4.
Frequency response: In the range of 0 to 10 kHz, the frequency response is+0 to -3 decibels, suitable for various mechanical monitoring applications.
Environmental temperature: 0 ° C to 45 ° C (III), incremental scaling factor (ISF) of 7.87 V
(200 mV/mil), gain error of ± 12.5% 2.Installation and maintenance
Installation method: The preamplifier should be installed floating and electrically insulated from the unit. It is recommended to use a preamplifier protection box for protection.
Cable type: Use three core shielded cables, with a length of up to tens of meters, and the shielding layer should be connected to the instrument ground at a single end in the control room
