Bently Nevada 3500/05-01-02-00-00-00(RACK) - SYSTEM RACK
BENTLY SYSTEM RACK
Origin: United States
Brand: Bently Nevada
3500/05-01-02-00-00-00 is a System Rack manufactured by Bently Nevada as a part of the 3500/05 series used in machinery condition monitoring systems. All 3500 monitor modules and rack power supply are housed in the Bently Nevada 3500/05 System Rack. It enables the 3500 modules to interact with one another, as well as the power supplies to distribute electricity to each module as needed.
Related products
Product Introduction
Rack Size
There are two sizes of 3500 Racks available:
Full-size Rack: 19-inch EIA rack with 14 module slots available
Mini-Rack: 12-inch rack with 7 module slots available
Panel Mount
This rack style attaches to rectangular cut-outs in panels with clamps provided with the rack.
From the back of the rack, you may access wiring connections and I/O modules.
Rack Mount
The 3500 racks are mounted on 19-inch EIA rails in this rack type.
From the back of the rack, you may access wiring connections and I/O modules.
Bulkhead Mount
When access to the back of the rack is restricted, this rack type places the rack against a wall or panel. From the
front of the rack, you may access wiring connections and I/O modules. This format does not support the
3500/05 Mini-Rack.
The Rack Interface Module and Power Supplies must be installed in the far left rack position. Any combination of
modules can be used in the remaining 14 rack locations (7 rack positions for the Mini-Rack).
