SIEMENS 6SE7041-3TL86-3AF0 Frequency Converter

The Siemens inverter 6SE7041-3TL86-3AF0 is a member of the Siemens SIMOVERT MASTERDRIVES product series and is a fully digitally controlled AC variable frequency transmission device. It uses IGBT voltage source PWM technology to provide high speed, high precision and high reliability performance.

Category:
Share

Related products




Product Introduction

6SE7041-3TL86-3AF0 Siemens Incoming Reactor

The production process of the dedicated incoming reactor for the inverter requires the coil and the iron core of the dedicated incoming reactor for the inverter to be assembled into one, and then go through the process of pre-baking → vacuum varnishing → hot baking and curing.



The dedicated incoming reactor for the inverter adopts H-class varnish to firmly combine the coil and the iron core of the reactor, which not only greatly reduces the noise during operation, but also has an extremely high heat resistance level, which can ensure that the reactor can run safely and noiselessly at high temperatures.



The Siemens inverter 6SE7041-3TL86-3AF0 is a member of the Siemens SIMOVERT MASTERDRIVES product series and is a fully digitally controlled AC variable frequency transmission device. It uses IGBT voltage source PWM technology to provide high speed, high precision and high reliability performance.



Main functional features

Fully digital control: The control function of the inverter is defined by internal software and can be customized through functional parameters. These function parameters can be used to set the input signal normalization, the acceleration and deceleration time of the ramp function, and the proportional coefficient (Kp) and the integral time (Tn) in the speed regulator.



High-performance IGBT technology: The voltage source PWM (pulse width modulation) technology using IGBT (insulated gate bipolar transistor) ensures the high efficiency and stability of the inverter.



Flexible parameter settings: Function parameters can be labeled and stored in different labels, and the specific meaning depends on the parameter definition. This flexibility allows users to adjust the performance of the inverter according to specific application requirements.



Support for multiple communication protocols: Siemens inverters support multiple communication protocols, which are easy to integrate into different control systems for remote monitoring and control.



Energy recovery function: In certain modes, the inverter can be used as an energy recovery device to feed back the regenerated energy to the power grid, thereby improving the overall energy efficiency of the system.



Significant energy saving effect

The Siemens 6SE7041-3TL86-3AF0 inverter can effectively control the speed and output power of the motor, realize load regulation, and thus achieve energy saving. Compared with the traditional resistance or reducer speed control method, it can save energy.



High-performance motor control and protection

The inverter has high-performance motor control and protection functions, which can monitor the working status and load of the motor in real time, and automatically adjust the output power to ensure the stability and reliability of the motor operation. In addition, it also has multiple safety protection functions such as overload protection, overheating protection, and short circuit protection, which effectively extend the service life of the equipment.



Digital control technology

Adopting advanced digital control technology, the 6SE7041-3TL86-3AF0 inverter can realize speed regulation and position control. Through current and voltage control, the motor can be started smoothly and stopped quickly, improving production efficiency and product quality.



Versatility

Supports multiple working modes and control methods, and can adapt to different working environments and needs. Parameters can be set and adjusted through programming software to achieve switching and combination of multiple functions to meet the requirements of different application fields.



Convenient maintenance

With a friendly human-machine interface and simple operation method, the working status and fault information of the equipment can be intuitively displayed. It also supports remote monitoring and diagnosis functions, and can obtain the operating data and fault information of the equipment in real time through the network, which is convenient for timely repair and maintenance.



Applicable to a variety of industrial fields

Due to its wide applicability and versatility, Siemens 6SE7041-3TL86-3AF0 inverter is widely used in various industrial fields, providing users with reliable power control solutions.



I think you'll find our product offers great value for money!

It's my pleasure to introduce our latest product, which will be a great addition to your current offerings!

We're thrilled to introduce you to our latest product, which we believe will meet your needs perfectly!

We believe this product can help to expand your market share. We look forward to the opportunity to work with you!



We sincerely welcome your calls and consultations and provide you with quality service 24 hours a day!



· Many products are not yet on the shelves please contact us for more products.

· If there is inconsistency between the product model and the display picture, the model shall prevail, please contact us for specific product pictures, we will arrange to take pictures in the warehouse to confirm!
