SIEMENS 6SE7041-2WL86-4DE0 Frequency Converter

Siemens inverter 6SE7041-2WL86-4DE0 provides excellent performance and reliability for industrial applications through its efficient energy feedback, low harmonic current consumption, reactive power compensation, low harmonic components and simplified system configuration. These functions work together to not only improve the energy efficiency of the system, but also enhance the stability and maintainability of the system.

Category:
Share

Related products




Product Introduction

The Siemens frequency converter 6SE7041-2WL86-4DE0 is a high-performance industrial device whose functions are designed to improve energy efficiency, system stability and ease of operation. Here are some of the drive’s key features:

Efficient energy feedback

The frequency converter supports 100% braking power regeneration, which means it can perform continuous braking without the need for a braking resistor. This feature not only simplifies system configuration but also increases the overall efficiency of the system by avoiding the additional heat generated by the braking resistor12.



Low harmonic current consumption

Siemens 6SE7041-2WL86-4DE0 inverter optimizes the current waveform, making the current waveform close to a sine wave, thereby significantly reducing reactive power distortion. This feature helps reduce power system losses by approximately 40% and reduces the need for transformer rated power.



Reactive power compensation

The frequency converter is able to compensate for the reactive power of motors and other inductive loads on the same power supply, thus improving the power factor (cosφ) of the entire system. This not only helps to reduce the total power consumption of the system, but also improves the power quality, especially when sharing the same power supply with other motor frequency converters, the total power consumption can be reduced by up to 12%.



Low harmonic content

Compared with standard frequency converters, frequency converters using feed technology have greatly reduced harmonic components. In particular, harmonics up to the 11th order are significantly lower than the values specified in relevant standards. This helps reduce disruption to the grid and ensures the system operates more smoothly.



 Simplify system configuration

Since there is no need to configure braking resistors and external components, Siemens 6SE7041-2WL86-4DE0 inverter simplifies the installation and maintenance of the system, while reducing additional management burdens such as heat dissipation monitoring.



Full digital control technology

As a member of the Siemens SIMOVERT MASTERDRIVES product series, 6SE7041-2WL86-4DE0 uses advanced full digital control technology and IGBT voltage source pulse width modulation (PWM) technology to ensure efficient operation and high-precision control of the equipment.



Vector control and motion control

Vector control: Provides precise torque control and fast dynamic response, suitable for applications requiring high accuracy, such as motor positioning and servo control.

Encoderless vector control: suitable for simple applications such as fans and water pumps, controlling the motor speed by adjusting the U/f ratio.



Customization of function parameters

Input signal normalization: allows users to normalize different input signals to adapt to different control systems.

The acceleration and deceleration time of the ramp function: used to smooth the motor starting and stopping process and avoid mechanical shock.

The proportional coefficient (Kp) and integral time (Tn) in the speed regulator: are key parameters of PID adjustment, used to adjust the stability and response speed of the system.



In terms of hardware, the 6SE70 inverter includes a main control board (CUVC board) responsible for overall control, a power board that provides drive circuits and power management, and a DP communication board (CBP2) that supports high-speed data transmission, enhancing the communication capabilities and scalability of the device.



I think you'll find our product offers great value for money!

It's my pleasure to introduce our latest product, which will be a great addition to your current offerings!

We're thrilled to introduce you to our latest product, which we believe will meet your needs perfectly!

We believe this product can help to expand your market share. We look forward to the opportunity to work with you!



We sincerely welcome your calls and consultations and provide you with quality service 24 hours a day!



· Many products are not yet on the shelves please contact us for more products.

· If there is inconsistency between the product model and the display picture, the model shall prevail, please contact us for specific product pictures, we will arrange to take pictures in the warehouse to confirm!
