Product Introduction

technical parameter
Frequency range: There are two options available: 10Hz-1000Hz and 4Hz-1000Hz.
Amplitude: The maximum amplitude measured can reach 2mm-3mm (peak to peak).
Sensitivity: There are multiple sensitivity options available, such as 22mV/mm · s, 28.5mV/mm · s, 30mV/mm · s, etc., depending on the type of measuring amplifier.
Natural frequency: between 4Hz-13Hz, depending on different sensor models.
Working temperature range: Sensors (excluding connectors) typically range from -20 ° C to+150 ° C, with instantaneous (<4h) up to -20 ° C to+220 ° C.
Protection level: generally IP55 or IP65.
Capacitor: including cables, generally less than 2.5nF.
DC impedance: The measurement coil includes an internal resistance of generally 1800 Ω± 12%, etc.

Product Features
High sensitivity: capable of accurately measuring small vibrations.
Strong anti-interference ability: The measurement coil has high output and low impedance, which can effectively resist external interference.
Durable and sturdy: With a sturdy casing, it can adapt to harsh industrial environments and withstand certain accelerations and vibrations.
Easy installation: There are multiple installation methods and different installation directions to choose from, making it easy to install on various devices.
Application areas: It can be applied to various industrial measurement fields, especially vibration measurement of various turbomachinery, fans, compressors, gearboxes, water pumps, coal mills and other equipment. It can also be used for power plant DCS monitoring systems, intelligent flat steel furnace system manufacturing, PLC programmable conveying control systems, DCS distributed control systems, etc.

Many products are not yet on the shelves please contact us for more products.

If there is inconsistency between the product model and the display picture, the model shall prevail, please contact us for specific product pictures, we will

arrange to take pictures in the warehouse to confirm!
