Product Introduction

Product Features
Non contact measurement: The sensor does not come into contact with the measured object, does not interfere with the measured object, and does not affect the measurement accuracy due to wear and tear. It is suitable for various high-speed rotation and high-precision measurement occasions.
High precision: capable of accurately measuring small displacement and vibration changes, with measurement accuracy reaching micrometer level or even higher.
High reliability: Adopting advanced electronic technology and manufacturing processes, it has good stability and anti-interference ability, and can operate reliably in harsh industrial environments for a long time.
Multiple measurement functions: In addition to measuring vibration and displacement, it can also be used to measure various physical quantities such as clearance between rotating and fixed parts, shaft eccentricity, shaft bending, bearing wear, oil film thickness, and relative thermal expansion between shaft and bearing.
Wide applicability: Suitable for monitoring and protection of various industrial equipment such as turbomachinery, fans, compressors, gearboxes, water pumps, coal mining machines, etc. It can also be used for laboratory research and teaching.

technical parameter
Measurement range: generally 1mm to 20mm, but different models may vary.
Thread size: There are metric or imperial threads available for selection, such as Φ 6mm, Φ 10mm, and Φ 18mm.
Cable options: Different lengths of cables, waterproof joints at cable ends, or bare wire methods can be selected according to the model. Cables can also be armored or unarmored, with or without joints at 1m cable locations.
Applicable temperature: usually -35 ℃ to+380 ℃.
Output signal: Generally, it is an AC voltage signal proportional to shaft vibration superimposed on a DC voltage, with an internal resistance of 100k Ω and a response time of 15 μ s.
Accuracy: Linear error varies depending on the type of sensor used.
