Product Introduction

Electrical characteristics
input parameter

Voltage range: It may support AC 90V-264V wide voltage input to adapt to the power supply and voltage fluctuation environment in different regions.

Frequency range: The input frequency is likely to be between 50Hz and 60Hz.

Output parameters
Output voltage: It may provide common DC voltage outputs, such as 24V, 48V, etc. Specifically for PM33211B-5-1-3-F, the output may be 24V or other standard values.

Output current: The expected output current may be around 10A to 30A depending on its application scenario and power level, which can supply power to a certain scale of load

equipment.

Output power: Based on the possible output voltage and current, the output power may be between 200W and 600W.

physical characteristics
Size specifications: Standard 1U or 2U height rack mounted design may be used, with a width of 19 inches and a depth ranging from 300mm to 500mm.

Shell material: Aluminum alloy or cold-rolled steel plate material is usually used for the shell to ensure good heat dissipation and electromagnetic shielding performance.

Weight: The estimated weight is around 3kg-8kg.

Protection function
Overvoltage protection: When the output voltage exceeds the safety threshold, such as 10% -20% of the rated output voltage, the power supply will automatically cut off the

output to protect the load equipment.

Overcurrent protection: When the output current exceeds the rated value, such as reaching 120% -150% of the rated current, the overcurrent protection mechanism is triggered to

limit the output current or cut off the output.

Overheating protection: There is a temperature sensor inside, which automatically reduces the output power or cuts off the output when the internal temperature of the power

supply reaches 80 ℃ -90 ℃, and resumes operation after the temperature drops.

Short circuit protection: When a short circuit occurs at the output terminal, it can quickly detect and cut off the output, and automatically restore the output after troubleshooting.

Many products are not yet on the shelves please contact us for more products.

If there is inconsistency between the product model and the display picture, the model shall prevail, please contact us for specific product pictures, we will

arrange to take pictures in the warehouse to confirm!
