Product Introduction

Product Overview

Technical features and functions
Input and output interface
The A1A10000423.00M power unit has the functions of analog I/O channels and digital I/O channels, which enables it to serve as a bridge between computers and external devices to achieve effective communication and data exchange.
It can collect signals from external devices, including analog signals and digital signals, and convert these signals into digital signals that can be processed by computers through corresponding interfaces.

Data communication
Realize data communication between computers and external devices, including uplink communication and downlink communication.
Uplink communication: upload the collected data to the computer for processing and analysis.

Downlink communication: receive the control instructions of the computer and convert them into corresponding control signals to send to external devices.

Control function
According to the collected signals and the control instructions of the computer, the external device is precisely controlled.

Technical specifications
Input and output type: supports both digital I/O and analog I/O channels (depending on the application scenario and configuration).

Power phases: 3 phases

Rated voltage: 690V (some say the system power supply voltage is 2.4~10KV, but here it refers specifically to the rated voltage of the board).

Applicable motor power: a wide range, such as 200kW~10000kW (depending on the system configuration and application requirements).

Control method: may include VVVF vector control (the specific control method may vary depending on the application).

Output voltage adjustment method: PWM control.

Dimensions: about 300mm×15mm×150mm (width×height×thickness, the specific dimensions may vary depending on the product version or configuration)

Communication and data exchange advantages
Multiple types of I/O channels
A1A10000423.00M power unit has the functions of analog I/O channels and digital I/O channels, which enables it to serve as a bridge between computers and external devices to achieve effective communication and data exchange, and can collect analog signals and digital signals from external devices and convert them into digital signals that can be processed by computers.

Data communication advantages
Two-way communication function
In terms of data communication, uplink and downlink communication between computers and external devices can be realized. Uplink communication can upload the collected data to the computer for processing and analysis; downlink communication can receive the computer's control instructions and convert them into corresponding control signals to send to external devices.

Control function advantages
Precise control of external devices
According to the collected signals and the computer's control instructions, the external devices can be precisely controlled.

System reliability advantages
The system can still operate in the event of a fault
Using power unit bypass technology, when A1A10000423.00M fails as a power unit, the inverter can still continue to operate at a reduced rating, greatly improving the reliability of the system.

Adaptability advantages
Adaptable to a variety of power motors
The adaptable motor power range is wide, such as 200kW - 10000kW (depending on the system configuration and application requirements), which can adapt to motors with different power requirements and can be applied to a variety of industrial scenarios.
Multiple control modes
The control mode may include VVVF vector control (the specific control mode may vary depending on the application). The control mode can be flexibly selected according to different application scenarios, which increases its adaptability.

Application scenarios
The A1A10000423.00M power unit is widely used in various industrial automation control scenarios due to its versatility and reliability. It can be used as an important part of the control system to achieve precise control and management of production equipment and improve production efficiency and quality.

I think you'll find our product offers great value for money！

It's my pleasure to introduce our latest product, which will be a great addition to your current offerings！

We're thrilled to introduce you to our latest product, which we believe will meet your needs perfectly！

We believe this product can help to expand your market share. We look forward to the opportunity to work with you！

We sincerely welcome your calls and consultations and provide you with quality service 24 hours a day！

· Many products are not yet on the shelves please contact us for more products.

· If there is inconsistency between the product model and the display picture, the model shall prevail, please contact us for specific product pictures, we will arrange to take pictures in the warehouse to confirm!
