Product Introduction

1. Basic Information
Model: 6SE7036-5GS87-1FE0
Brand: SIEMENS
Type: servo system dedicated inverter/output reactor module, suitable for industrial automation scenarios.
Input Voltage: Supports DC 510-620V (adaptive motor power range 0.5kW~315kW, specific configuration confirmation required).
Installation Method: Modular onboard installation, suitable for standard industrial cabinet layout.

2. Core Functions and Technical Features
2.1 Servo Control and Dynamic Response
- Designed for high-precision servo systems, supports speed control, torque control and position control, with excellent dynamic response performance, suitable for CNC machine tools, industrial robots and other scenarios.
- Integrated high-precision sensor interface, real-time monitoring of motor load status, automatic adjustment of output power.

2.2 Output Reactance Function‌
-- As an output reactor, it compensates for the charging and discharging effects of coupling capacitors when long cables (>50m) are running, suppresses harmonics (THD<5%), and avoids overcurrent of the inverter.
-- Supports two types: iron core type (carrier frequency <3kHz) and ferrite type (carrier frequency <6kHz), which are suitable for different inverter configurations.

‌2.3 Protection and Stability‌
-- Integrated overcurrent protection, overvoltage protection (DC bus overvoltage trigger) and short-circuit protection to ensure safe operation of the equipment.

‌-- IP66 protection level, suitable for harsh industrial environments such as dust and moisture.

‌Communication and Integration‌
Supports Profibus-DP communication protocol, seamless networking with Siemens PLC (such as S7 series), and remote monitoring and parameter debugging.
Optional PROFINET and EtherCAT expansion modules support multi-axis collaborative control .

3. Technical parameters

Input voltage: DC 510-620V

Applicable motor power: 0.5kW~315kW (depending on the configuration)

Output frequency range: 0-200Hz (expandable to higher frequencies)

Instantaneous overload capacity: 200% rated current (for 1 second)

Communication interface: Profibus-DP, PROFINET (optional)

Protection level: IP66

4. Application scenarios

High-precision processing equipment: CNC machine tools, precision engraving machines, etc., supporting 0.001mm positioning accuracy.

Industrial robots: Multi-axis collaborative control to achieve complex motion trajectories.

Long cable drive scenarios: Long-distance cable connection of equipment such as fans and water pumps to suppress harmonic interference.

5. Use and Maintenance Specifications
5.1 Parameter Configuration
-- Set motor parameters through Siemens Starter software (P101/P102 is rated voltage/current, P100 selects control mode).
-- Restore factory settings: set P053=7, P060=2, P366=0, and start parameter reset through P970=0.

5.2 Installation Requirements

Ensure that the power wiring phase sequence is correct and avoid high temperature (＞70℃) and strong vibration environment.
In long cable scenarios, output reactors must be installed to prevent overcurrent faults.

5.3 Maintenance Recommendations

Clean heat dissipation components regularly, check the status of fastening bolts, and perform insulation tests every six months.
Monitor the stability of the communication interface and check for signal interference risks.
With high-precision servo control, long cable harmonic suppression and industrial-grade protection as its core advantages, this model is suitable for automated processing, robots and complex industrial drive scenarios.
