Product Introduction

1. Basic Information
Model: 6SE7036-5UK84-1BH0
Brand: SIEMENS
Series: SINAMICS S120 series drive control module, designed for high-precision industrial automation scenarios.
Input Voltage: Rated voltage 380V, suitable for three-phase AC power supply system.
Installation Method: Modular onboard installation, suitable for standard industrial cabinet layout.

2. Core Functions and Technical Features
2.1 Multi-mode Control Capability
-- Supports V/F control (scalar control), vector control and servo control, can drive three-phase asynchronous motors, synchronous motors, linear motors, etc., covering basic speed regulation to high-precision dynamic response requirements.
-- Integrated direct torque control (DTC) technology, fast response can be achieved without encoder (such as crane and elevator scenarios).

‌2.2 Modularity and scalability‌
-- Adopting ‌modular design‌, it supports flexible combination with rectifiers and communication modules, and realizes power expansion through parallel connection‌.
-- Compatible with ‌DRIVE-CLiQ communication technology‌, and supports multi-machine collaborative control (a single control unit can simultaneously manage 4 inverters + 1 rectifier).

‌2.3 Communication and integration‌
-- Supports ‌PROFIBUS DP‌ and ‌PROFINET‌ protocols, and seamlessly integrates with Siemens PLC (such as S7 series) to achieve remote monitoring and data interaction‌.
-- Optional ‌USS protocol‌, adapting to simple serial communication requirements‌.

‌2.4 Protection and energy efficiency optimization‌
-- Integrated ‌overcurrent protection‌, ‌overvoltage protection‌ (DC bus voltage monitoring), ‌overheating protection‌ and ‌ground fault protection‌ to ensure stable operation of the equipment‌.
-- Supports ‌energy feedback function‌, which feeds back braking energy to the power grid, significantly improving energy-saving efficiency‌.

3. ‌Technical parameters‌
Rated input voltage: 380V (three-phase AC)‌
Output frequency range: up to 50000Hz (depending on the configuration)‌
Protection level: IP66 (dust and moisture resistant)‌
Communication interface: PROFIBUS DP, PROFINET, USS‌
Instantaneous overload capacity: 200% rated current (for 1 second)‌

4. ‌Application scenarios‌
‌High-precision industrial equipment‌: CNC machine tools, industrial robots and other scenes that require dynamic response and positioning accuracy‌.
‌Energy-saving system‌: variable load equipment such as fans and water pumps, which reduce energy consumption through speed regulation and energy feedback‌.
‌Multi-machine collaborative control‌: multi-motor collaborative drive of complex mechanical systems such as production line conveyor belts and extruders‌.

5. Recommendations for use and maintenance

5.1 Parameter configuration
-- Set motor parameters (such as rated voltage P101, current P102) through the Siemens Starter software, and select the appropriate control mode (such as vector control P100).
-- Restore factory settings: parameters P053=7, P060=2, P970=0.

5.2 Installation requirements
-- Avoid high temperature (＞70℃) and strong vibration environment, and ensure sufficient heat dissipation space.
-- The power wiring must meet the phase sequence requirements to avoid poor contact and cause failure.

5.3 Maintenance points
Regularly check the cooling fan and capacitor status, and perform insulation tests every six months.
Monitor the stability of the communication interface and check for signal interference (such as ground fault F0012).
This model has multi-mode control, modular expansion and high-efficiency feedback as its core advantages, and is suitable for high-precision manufacturing, energy-saving optimization and complex industrial drive scenarios.
