Product Introduction

High efficiency: Provides excellent power output and control accuracy.

Energy-saving design: Achieve energy savings by optimizing motor operating efficiency and reducing energy loss.

Easy maintenance: Modular design makes maintenance and troubleshooting easier.

Flexible configuration: Supports multiple control modes and parameter settings to meet the needs of different application scenarios.

Input voltage: Depending on the specific model, it is usually 380V to 690V.

Output current: Depending on application requirements, it ranges from 0.5A to 630A.

Frequency range: Usually 50Hz to 60Hz, which can be adjusted to adapt to different grid conditions.

Control function:

Vector control: Achieve high-precision speed and position control.

Start-stop characteristics: Smooth start and stop, reduce mechanical shock.

Regenerative braking: Convert kinetic energy into electrical energy and feed it back to the grid during deceleration to improve energy efficiency.

The easy-to-use STARTER commissioning tool can be used for:
Commissioning
Optimization and diagnostics

The software can be operated as a stand-alone application, integrated in SIMATIC STEP 7 with TIA compatibility via Drive ES Basic or integrated in the SCOUT engineering system for SIMOTION. The basic functions and operation are identical in both cases.

In addition to SINAMICS frequency converters, STARTER also supports MICROMASTER 4 devices.

Using the project wizard, you can add the drive system to the project structure tree.

The solution-oriented dialog navigation supports beginners, while the graphical display helps you understand when setting the drive parameters.

***Commissioning is guided by a wizard that takes you through all the basic settings in the drive system. As a result, you only need to set a few parameters as part of the drive configuration process to get the motor up and running.

The individual settings required are parameterized using a graphic-based interface that also shows the operating principle of the drive system.

Examples of individually configurable settings include:

How to use the terminals

Bus interface

Setpoint channel (e.g. fixed setpoints)

Closed-loop speed control (e.g. ramp-function generator, limit values, etc.)

BICO interconnection

Fault diagnostics

Experts can use the expert list to access individual parameters clearly and quickly at any time. Individual edits of frequently used parameters can be saved in special user lists and monitoring tables.

In addition, the following functions are available for optimization:

Self-optimization of controller settings (depending on the drive unit)

Tracking

(depending on the inverter unit, this function is not supported

MICROMASTER 4

SINAMICS G110

SINAMICS G120

SINAMICS G110D

SINAMICS G120D)

The diagnostic function provides the following information:

Control/status word

Parameter status

Conditions of use

Communication status

Performance features

Easy operation: Only a few settings are required for successful first commissioning: The motor starts running

Solution-oriented dialog user guidance simplifies the commissioning process

Self-optimization function reduces the time spent on manual optimization

System requirements

The following system requirements must be met:

Hardware

PG or PC with Pentium III processor, at least 1 GHz (> 1 GHz recommended)

Work memory 1 GB (2 GB recommended)

Screen resolution 1024 × 768 pixels, 16-bit color depth

Free hard disk space: min. 3 GB

Software

Microsoft Internet Explorer V6.0 or higher

32-bit operating system:

Microsoft Windows Server 2003 SP2

Microsoft Windows Server 2008

Microsoft Windows XP Professional SP3

Microsoft Windows 7 Professional SP1

Microsoft Windows 7 Ultimate SP1

Microsoft Windows 7 Enterprise SP1 (standard installation)

64-bit operating system:

Microsoft Windows 7 Professional SP1

Microsoft Windows 7 Ultimate SP1

Microsoft Windows 7 Enterprise SP1 (standard installation)

Microsoft Windows Server 2008 R2

The SINAMICS S120/SINAMICS S150 Control Units can be connected via PROFIBUS or PROFINET/Ethernet or via serial RS232 The interfaces communicate with each other, depending on the type of Control Unit (DP or PN).

For this purpose, the PG/PC requires a PROFIBUS communication board and a connecting cable.

If the optional CBE20 PROFINET communication board is available, this can be used to provide the communication link between the CU320-2 and the PG/PC.
