SIEMENS 6SE7041-1GM84-1CF0 Frequency Converter

Siemens inverter 6SE7041-1GM84-1CF0 is a frequency converter designed for industrial automation, with high efficiency and high reliability. This frequency converter is widely used in various industrial machinery and equipment, improving production efficiency and reducing energy consumption by accurately controlling motor speed.

Category:
Share

Related products




Product Introduction

1. Motion control with frequent changes in speed and direction of rotation

The Siemens inverter 6SE7041-1GM84-1CF0 is able to handle motion control tasks that require frequent changes in speed and direction of rotation. This capability makes it well suited for applications such as automated warehousing, system centrifuges, and renewable energy (such as electricity and wind power generation).



2. Electric braking quality

The inverter has a regenerative feedback function that can play a role in applications that require electric braking quality. This is particularly meaningful for applications that require high braking power for a long time, as it can reduce costs and required space.



3. Vertical motion applications

The Siemens inverter 6SE7041-1GM84-1CF0 is also suitable for applications with vertical motion, such as conveyor vehicle drives, theater stage machinery equipment, and brake test systems. These applications often require high-precision speed control and stable operating performance.



4. Drive loads with high moments of inertia

The inverter also performs well for drive loads with high moments of inertia. It can effectively manage and control these loads to ensure system stability and efficiency.



5. Effective rectification technology

To further reduce costs and required space, the Siemens inverter 6SE7041-1GM84-1CF0 uses effective rectification technology. This technology is particularly useful in applications where high braking power needs to be applied for a long time.



6. Integrated Class A EMC filter and energy regeneration function

The inverter integrates Class A EMC filter and energy regeneration function, which helps to reduce electromagnetic interference and improve the overall efficiency of the system. In addition, its topology allows for a larger effective capacitance at the input of the inverter than traditional power modules, thereby providing higher capacitive reactive current when the power module is powered on.



7. Software support and debugging tools

The Siemens inverter 6SE7041-1GM84-1CF0 supports a variety of software tools, such as the STARTER debugging tool, which is easy to operate and can be used to debug, optimize and monitor the drive system. It can also be integrated into TIA-compatible SIMATIC STEP7 or into the SCOUT engineering system to facilitate configuration and maintenance by engineers.



8. Parameter setting and monitoring

Through the graphical parameter setting interface, users can easily set and monitor drive parameters. This allows even inexperienced operators to quickly get started, and can reduce the time required for manual optimization through the self-optimization function.



The STARTER commissioning tool is easy to use and can be used for:

Commissioning (Commissioning)

Optimization and

Diagnostics

The software can be operated as a stand-alone application, integrated in SIMATIC STEP 7 with TIA compatibility via Drive ES Basic, or integrated into the SCOUT engineering system (for SIMOTION). Its basic functions and operation are the same in both cases.



In addition to SINAMICS frequency converters, STARTER also supports MICROMASTER 4 devices.



Using the project wizard, you can add the drive system to the project structure tree.



The solution-oriented dialog window navigation function can support beginners, while the graphical display function helps to understand when setting the drive parameters.



*** Commissioning is guided by the wizard function, which completes all basic settings in the drive system. Therefore, as part of the drive configuration process, you only need to set a few parameters to start and run the motor.

The required individual settings use a graphic-based parameterization interface, which also *** shows the operating principle of the drive system.



Examples of individually configurable settings include:



How to use the terminals



Bus interface



Setpoint channel (e.g. fixed setpoints)



Closed-loop speed control (e.g. ramp-function generator, limit values, etc.)



BICO interconnection



Fault diagnostics



Experts can use the expert list to access individual parameters clearly and quickly at any time. Individual edits of frequently used parameters can be saved in special user lists and monitoring tables.



In addition, the following functions are available for optimization:



Self-optimization of controller settings (depending on the drive unit)



Tracking (depending on the inverter unit, this function is not supported)



MICROMASTER 4



SINAMICS G110



SINAMICS G120



SINAMICS G110D



SINAMICS G120D)



The diagnostic function provides the following information:



Control/status word



Parameter status



Conditions of use



Communication status



Performance characteristics



Easy operation: Only a few settings are required for successful first commissioning: The motor starts running



Solution-oriented dialog user guidance simplifies the commissioning process



Self-optimization function reduces the time spent on manual optimization



System requirements



The following system requirements must be met:



Hardware



PG or PC with Pentium III processor, at least 1 GHz (> 1 GHz recommended)



Work memory 1 GB (2 GB recommended)



Screen resolution 1024 × 768 pixels, 16-bit color depth



Free hard disk space: min. 3 GB



Software



Microsoft Internet Explorer V6.0 or higher



32-bit operating system:



Microsoft Windows Server 2003 SP2



Microsoft Windows Server 2008



Microsoft Windows XP Professional SP3



Microsoft Windows 7 Professional SP1



Microsoft Windows 7 Ultimate SP1



Microsoft Windows 7 Enterprise SP1 (standard installation)



64-bit operating system:



Microsoft Windows 7 Professional SP1



Microsoft Windows 7 Ultimate SP1



Microsoft Windows 7 Enterprise SP1 (standard installation)



Microsoft Windows Server 2008 R2

The SINAMICS S120/SINAMICS S150 Control Units can be connected via PROFIBUS or PROFINET/Ethernet or via serial RS232 The interfaces communicate with each other, depending on the type of control unit (DP or PN).



For this purpose, the PG/PC requires a PROFIBUS communication board and a connection



If the optional CBE20 PROFINET communication board is available, this can be used to provide the communication link between the CU320-2 and the PG/PC.
