Product Introduction

1. Core Features‌
‌1.1 High-performance drive control‌

-- Adopts ‌vector control technology‌, supports high-precision motor speed regulation, adapts to three-phase AC motors (such as fans, water pumps, conveyors, etc.), and improves dynamic response and operating efficiency‌.
-- The output frequency can be adjusted in a wide range, supports ‌three-phase AC 380-480V input‌, and is compatible with a variety of industrial scene requirements‌.

‌1.2 Modular and compact design‌

‌-- Book-type modular structure‌, easy to stack and install, adapt to standard control cabinet layout, save space and simplify maintenance process‌.
-- Built-in ‌resistor harmonic suppression module‌, effectively absorbs grid harmonics and overvoltage, and ensures system stability‌.

‌1.3 Industrial-grade safety and compatibility‌

-- Integrated ‌STO (safe torque off) function‌, complies with industrial safety standards, and ensures the safety of equipment during emergency shutdown‌. -- Supports communication protocols such as Profibus and Profinet, seamlessly integrated into the automation control system, and realizes efficient data interaction.

‌2. Technical parameters‌

‌Input voltage‌: three-phase AC ‌380-480V‌, 50/60Hz‌
‌Output frequency‌: supports ‌24Hz‌ adjustable output, adapting to various speed regulation requirements‌
‌Rated power‌: adapts to ‌medium and high power motors‌ (specific power needs to be combined with configuration)‌
‌Protection level‌: ‌IP20/IP30‌ (depending on the installation environment), needs to be installed in the control cabinet‌
‌Communication interface‌: RS 485, Ethernet, Profibus, supports real-time data transmission and remote monitoring‌

3. Typical application scenarios‌
‌Industrial drive control‌: suitable for energy-saving speed regulation and efficiency optimization of equipment such as fans, water pumps, and compressors‌.
‌Production line automation‌: control conveyor belts, packaging machinery, etc., to improve the accuracy and stability of the production process‌
‌Adaptation to complex environments‌: Resistant to harsh working conditions such as dust and moisture, widely used in building materials and environmental protection industries‌.

4. Installation and maintenance recommendations‌
‌4.1 Installation requirements‌

-- Fixed in the control cabinet, leaving sufficient heat dissipation space to avoid aging of components due to high temperature‌.

-- The input power supply must match the rated voltage range (380-480V) to prevent overload or voltage fluctuation‌.

‌4.2 Maintenance measures‌

‌-- Regular cleaning‌: Remove dust from the cooling fan and circuit board to ensure heat dissipation efficiency‌.

‌-- Capacitor detection‌: Detect the filter capacitor capacity every 1-2 years. If it is lower than 85% of the nominal value, it needs to be replaced‌.

‌-- Software support‌: Parameter calibration, fault diagnosis and system optimization are performed through Siemens ‌STEP 7 software‌.
