Product Introduction

Function of the board
Receive the signal of the main control system: provide control signals for the driver board.
Real-time fault monitoring: report fault information to the main control system.
Supply power to the unit driver board: ensure the normal operation of the driver board.
Board interface description
Fiber optic interface: communicate with the main control system.
24V power input interface: connected to the power board.
Drive signal interface: including Top1, Top2, Lock interface, connected to the driver board.
15V power output interface: power the driver board.
Fault detection interface: including overvoltage, undervoltage detection interface, phase loss detection interface, overheating detection interface, etc.

Application range
This control board is suitable for Siemens Robincon inverter, especially in G3 series power unit. It can effectively drive IGBT and monitor various fault conditions of the unit, thereby improving the reliability and stability of the entire system.

Technical parameters and performance characteristics
Voltage level: 690V, suitable for high voltage environment.
Working temperature range: 20℃~26℃ at room temperature.
Humidity range: 40%~65%.
Interface type: including optical fiber interface, 24V power input interface, drive signal interface, overvoltage and undervoltage detection interface, phase loss detection interface, overheating detection interface, power-on thyristor drive signal interface, bypass thyristor drive signal interface and bypass OK signal detection interface.
Interface type: with a variety of interfaces, including optical fiber interface and a variety of power and signal interfaces to meet different connection requirements.
Fault detection function: can monitor and report unit voltage division and overtemperature faults in real time to ensure safe and stable operation of the system.

Performance characteristics
High reliability: after rigorous design and testing, it ensures stable operation in various harsh environments.
Easy to maintain: with clear interface definition and detailed fault diagnosis function, it is easy to quickly locate and solve problems.
High efficiency: optimized circuit design and efficient power management improve the overall energy efficiency ratio.

Real-time fault monitoring and alarm
The control board has real-time fault monitoring function, which can detect and report fault information in time and effectively prevent potential safety hazards. This highly automated monitoring capability greatly improves the reliability and maintenance efficiency of the system.

Strong compatibility
The Siemens Robincon unit control board A1A10000432.01M has good compatibility and can be used with a variety of Siemens Robincon power modules to meet the needs of different customers.

Environmental adaptability
Designed with different working environments in mind, the control board can work stably in a normal temperature and humidity environment, and has dust and corrosion resistance, making it suitable for various industrial occasions.
